- Nominal overall diameter: 165 mm / 6.5”
- LF voice coil diameter: 38 mm / 1.5"
- HF voice coil diameter: 34 mm / 1.3" (titanium)
- RMS Power: 100 W
- Sensitivity: 93 dB
- Frequency range: 132-20000 Hz
- Nominal Impedence: 8 Ohm
- Flux Density: 1.2 T
- Recommended crossover frequency: 1.7 Khz
- Magnet material: Ferrite
- Voice Coil Winding Material: copper
- Voice Coil Former Material: Glass Fibre
- Cone Material: Paper
- Surround Material: Treated Cloth
- Baffle cutout diameter: 145 mm
- Recessed depth: 110 mm
- Net Weight: 2.9 kg
- Package: 4 pieces each box
